Product description

Product Description

Overview and Design

Nocpix Vista H50 – 1 unit

The Nocpix Vista H50 is a premium thermal monocular that combines compact, ergonomic tube-style design with advanced imaging technology—delivering high performance while remaining portable. It is designed for both daytime and nighttime use and performs well under challenging conditions such as fog, rain, or dense vegetation.

Imaging Performance

Thermal Sensor: 640×512 resolution with 12 µm pixel pitch – high sensitivity (NETD ≤ 15 mK) ensures sharp, clear images, capturing fine details such as animal silhouettes.

Lens: Fast 50 mm objective with f/0.9 aperture – captures ~20% more light than f/1.0 lenses, increasing brightness and clarity in low-light conditions.

Display: Circular AMOLED display, 2560×2560 resolution, 8 mm exit pupil, featuring “Pure Vision Mode” – delivers an immersive, comfortable viewing experience with minimal eye strain.

Frame Rate: 60 Hz refresh rate – smooth, seamless motion tracking, ideal for moving targets.

Features and Usability

Digital Zoom: 4× base optical magnification, seamless digital zoom up to 40× for detailed long-range observation.

Battery: Replaceable IBP-7 (4400 mAh) rechargeable batteries – swapped in seconds in the field; each lasts ~5 hours. Rechargeable via USB-C or inside the unit.

Controls and Comfort: Silent, tactile buttons, foldable/rotatable eyecup, and rubberized controls suitable for nighttime and gloved operation.

Build: Rugged ergonomic housing with near-silent spring-loaded lens cover and comfortable grip.

Extras: Comes with a quick-start guide, wrist strap, carry case, cleaning cloth, data cable, and two batteries.

Specifications: Detection range up to ≈2600 m (human-sized target, 1.7 m × 0.5 m); field of view ~15 m at 100 m.

Additional Functions: Multiple color palettes (including red and green) for eye comfort, Wi-Fi connectivity for app integration, recording options, and built-in image stabilization.

Technical Summary

Feature

Specification

Sensor

640×512 @ 12 µm, NETD ≤ 15 mK

Lens

50 mm, f/0.9

Display

AMOLED, 2560×2560, 8 mm exit pupil

Refresh Rate

60 Hz

Magnification

4× optical, up to 40× digital

Field of View

~15 m @ 100 m

Detection Range

≈2600 m (1.7 m × 0.5 m target)

Battery

2× IBP-7 (4400 mAh), ~5 hrs each

Connectivity

USB-C charging, Wi-Fi

Special Functions

Color palettes, image stabilization, recording

Weight

Slightly over 0.6 kg with battery

Accessories

Case, strap, cables, guide, cloth

Review Highlights

Field testing emphasizes excellent performance, especially for long-range observation. While the field of view is relatively narrow (~15 m/100 m), it excels in open terrain. Ergonomics, quick battery swap, and image quality are frequently praised.

Summary

The Nocpix Vista H50 stands out among high-end thermal monoculars—offering outstanding sensitivity, fast optics, a vivid AMOLED display, smooth operation, and rugged design. It is ideal for hunters and outdoor enthusiasts who demand precision and reliability in the field.
